• Input Impedance: 1 Mohms // 100 pF
• Character Filter:
  Low +7 dB @ 40 Hz
  Mid -2dB@ 800Hz
  High +3 dB @ 10 kHz
• Comp/limit:
  Gain 0 dB
  Attenuation max 24 dB
  Compression Ratio max 3:1
  Attack (80%) typ. <10 ms
  Release (80%) typ. 100 ms
• Bass Filter:
  Type 12 dB/oct. Shelving
  Gain Range +/-18dB @ 60Hz
• Middle Filter:
  Type Bandpass Filter
  Frequency Range 100 -6.000 Hz
  Gain Range +/-12-15 dB
• Treble Filter:
  Type Shelving
  Gain Range +/-18dB@6kHz
  Bright: Type Shelving
  Gain Range +15/-0 dB @ 10 kHz
• Balanced XLR output:
  Output Level Nominal -10dBv
  Frequency Response +0/-3 dB 10-20.000 Hz
  XLR Connections 1-GND, 2-Hot, 3-Cold
  Options GND Lift, Pre/Post EQ
• Effect Loop:
  Loop Signal Level nominal -10 dBv
  Gain Unity (1:1)
  Output Impedance 100 ohms
  Input Impedance >50 Kohms // 100 pF
• Line out:
  Output Impedance 100 ohms
  Signal Level nominal 0 dBv
• Phones out:
  Impedance recommended 32 -200 ohms
• Power amp:
  500 W
• External cabinet output:
  Minimum Load Impedance of external cabinet is 4 ohms
  Connect via Speakon output jack.
• Auxiliary output:
  Power Requirements max 500 W
  Mains Protection: T2.5A Fuse (230V) T5A Fuse (100/120V)
• Cabinet:
  Configuration: 2x 10" Neodymium Speakers + tweeter
  Frequency Response: 45 - 20k Hz
  Size: (H x W x D) 56 cm / 22" / 44 cm / 17.3" / 36.5 cm / 14.4"
  Weight (total): 15.4 kg / 33.95 lbs

Dust cover included.
